What this machine produces
Watch it run
Key features
Heavy-tonnage hydraulic clamping
Auto slide & open-close mould cycle
Larger platen size for higher cavity output
Fully automatic, multi-station operation
Also available for double-colour soles
Full specifications
Technical specifications for the TechRub-6 .
| Specification | Unit | DetailsTechRub-6 |
|---|---|---|
| No. of Stations | 6 | |
| Daylights | 2 | |
| Total Mould Capacity | 12 moulds in one time | |
| Clamping Force | 160 Tons | |
| Plate Size | mm | 500x450 |
| Heating System | Electric / Oil Heating System | |
| Control Panel | PLC Controlled | |
| Electric Motor | Servo Motor | |
| Daylight Gap | mm | 210 |
| Motor Power | 7.5 KW, 2.2 KW | |
| Heater Load | kw | 97.2 |
| Dimensions (LxWxH) | mm | 7300 x 2400 x 1950 |
| Weight | kg | 15000 |
Specifications subject to change without notice. Custom configurations available on request.
