What this machine produces

Watch it run
Key features
Full specifications
Technical specifications for the Technica-2 across available variants.
| Specification | Unit | Single StationTechnica 1 | Double StationTechnica 2 |
|---|---|---|---|
| Screw Diameter | MM | 65 | 65 |
| Screw Speed | RPM | 220 | 220 |
| Heating Load | KW | 3.2 | 6.4 |
| Electrical Motor | KW | 17 | 28 |
| Total Connected Load | KW | 20.2 | 34.4 |
| Clamping Force | Ton | 60/100/150 | 60/100/150 |
| Production Capacity | Pair/Hr | 30-120 | 60-220 |
| Standard Mould Size | MM | 300x400 | 300x400 |
| Net Weight | KGS | 1800 | 3700 |
| Machine Dimensions (WxLxH) | MM | 760x3350x2400 | 1524x3350x2400 |
| Capacity of Oil Tank | Ltrs | 250 | 420 |
Specifications subject to change without notice. Custom configurations available on request.
Frequently asked questions
Why is the TECHNICA-2 called the tap tap or tup tup machine?
Because its two mould stations work in tandem — tap, tap. That twin-station working gives the machine its nickname, and it is also why the TECHNICA-2 nearly doubles output per operator: 60–220 pairs per hour, against 30–120 on the single-station TECHNICA-1, in PVC, TPR and TPU. Share your sole type and target output on WhatsApp and we'll send a quotation within 24 hours.
