TECHNICA PV-1
PVC Paver Block Mould Making Machine — Compact
Compact single-station PVC paver block mould making machine — processes raw PVC resin directly for lower material cost, with a small footprint and low energy draw. Ideal for entry and mid-volume paver production.
What this machine produces
Watch it run
Key features
Full specifications
Technical specifications for the TECHNICA PV-1 .
| Specification | Unit | PV1Technica PV1 |
|---|---|---|
| Screw Dia | Mm | 90 |
| Heating Load | Kw | 6 |
| Electrical Motor | Kw | 20.5 |
| Total Connected Load | Kw | 26.5 |
| Clamping Force | Ton | 60 |
| Production Capacity | Pcs./Hour | 15-30 |
| Standard Mould Size | MM | 600x600 |
| Net Weight | Kg | 3500 |
| Machine Dimensions | MM | 900(W)X3700(L)X2850(H) |
| Oil Capacity | LTR | 250 |
Specifications subject to change without notice. Custom configurations available on request.
